LIGHT INDICATOR FOR PANEL TB/06/SQ-L
×
1 / 4
2 / 4
3 / 4
Technical drawings and data sheets are copyrighted
Our products have obtained the main marks of conformity from European and North American certification bodies. When requesting a sample or quotation, please specify the necessary approval requirements
LIGHT INDICATOR FOR PANEL TB/06/SQ-L
TECHNICAL DATA
Download pdfLamps
incandescent • neon/fluoro • LED red, yellow, orange, green, blue, white
Working voltage
2V • 6V • 12V • 24V • 48V • 110V • 250V • 400V
Working temperature
90°C Max • 120°C Max • 150°C Max
Hole diameter
6mm
Recommended thickness panel
from 0,5mm to 2mm
Method of connection to the panel
Self-locking
Type of connection
PVC cable • siliconecable • silicone-glass cable
Wire ends
on request
Type of lenses
SQ10 • SQ11 • SQ12 • SQ13 • SQ14 • SQ15 • SQ16 • SQ17 • SQ18 • SQ19 • SQ20
Light indicator for panel TB/06/SQ-L
The TB/06/SQ-L is a compact panel-mount light indicator with a self-locking front installation system and L-shaped body, ideal for applications where an angled cable exit or reduced space is required. Compatible with incandescent, NEON/FLUO, or LED lamps, it covers a wide voltage range from 2V to 400V. This versatile and durable solution is suitable for home appliances, Ho.Re.Ca. equipment, HVAC-R systems, industrial automation, and electrical panels, offering reliable performance even in technically demanding environments.
